Hithium Energy Storage 3.2 V 50Ah LiFePO4 Cylindrical Cells
Product Details:
Place of Origin: China
Brand Name: Hithium
Certification: CE
Model Number: LFP64151
Payment & Shipping Terms:
Retail Price: /
Wholesale Price: Negotiable
Packaging Details: cartons or plywoods
Payment Terms: T/T
- Nominal Capacity: 50 Ah Nominal Voltage: 3.2 V
- Internal Impedence: ≤ 0.7 mΩ Operating Voltage: 2.50 - 3.65 V
- Dimension: 64 x 151 mm Battery Weight: 1 kg ± 0.1kg
Product Description
In the respect of residential energy storage, another star product of Hithium — cylindrical cell, designed with 50Ah large capacity on the basis of a 64mm-diameter platform, shows three advantages as follows. In respect of its performance, cycle life of 8,000 times under 1C-rate meets customer’s demand of using 12-15 years. Compared with normal 50Ah prismatic battery, its cost can be decreased by over 10%. Otherwise, its flexibility and compatibility makes it possible to match with larger capacity and be placed flexibly.
Individual pricing for large scale projects and wholesale demands is available. We also offer sample orders on request for customers to assess the products and accessories. Get the export quality LiFePO4 batteries from the most reliable supplier. Buy low cost heavy-duty Lithium Iron Phosphate rechargeable battery of various capacities.
Product Features
- Low cost
- Supports low-temperature charging: capable of charging at -20°C for superior environmental adaptability
- Long service life: up to 8,000 cycles at 1C/1C with 70% SOH
- High flexibility and compatibility: flexibly compatible with mainstream household energy storage products
Specification
Basic Parameters
| Nominal Capacity | 50 Ah ¹·² |
| Nominal Energy | 160 Wh ¹·² |
| Chemistry | LiFePO4 (LFP) |
| Cycle Life | 8,000 ²·³·⁵ |
| Gravimetric Energy Density | ≥ 150 Wh/kg |
| Volumetric Energy Density | ≥ 330 Wh/L |
| Model | LFP64151 |
Electrical Parameters
| Nominal Voltage | 3.2 V ¹·² |
| Operating Voltage | T > 0°C 2.50 - 3.65 V T ≤ 0°C 2.00 - 3.65 V |
| Internal Resistance (1 kHz) | ≤ 0.7 mΩ ⁴ |
| Self-discharge Rate | 3%/month ²·⁴ |
| Max Continuous Charge C-rate | 1C |
| Max Continuous Discharge C-rate | 2C |
Mechanical Interface
| Dimensions (D x H) | 64 x 151 mm |
| Type | Cylindrical Cell |
| Weight | 1 kg +/- 0.1 |
| Volume | 0.48 L |
Temperature Range
| Charging | -20°C ~ 60°C |
| Discharging | -30°C ~ 60°C |
| Storage (Recommended) | -20°C ~ 35°C |
Product Certification
| Certifications & Reports | IEC 62619, UL 9540A, UL 1973 UN 38.3 |
Environmental Compliance
| Compliance | RoHS, REACH, Battery Directive |
Company Certifications
| Company Certifications | ISO 9001, ISO 14001, ISO 45001 |
1. *0.5C/0.5C*
2. *25°C +/- 2.0*
3. *70% SOH*
4. *27% SOC*
5. *1C/1C*
Details
Note
1.We battery is brand new and of Grade A quality. It comes with a QR code serial number and a factory inspection report that allows you to trace its origin.If you require Check a data report, please feel free to contact us.
2.We will test all battery voltage, internal resistance and capacity before delivery.
3.100% Eco-friendly, will not cause pollution pressure to the environment
